Keychron V3 Max QMK Wireless Custom Mechanical Keyboard ISO Layout Collection

SKU: V3M-D1-BO
€129,99
Tax included

Tуре
Layout Version
Switches

Keychron V3 Max QMK/VIA Wireless Mechanical Keyboard allows anyone to master keyboard keys or macro commands through VIA. ISO version includes Nordic layout, comes with extra keycaps suitable for both macOS and Windows devices, and users can hot-swap with any MX mechanical switch in a breeze.

ABS Keycaps: Backlight shine-through
PBT Keycaps: Non-shine-through




No discount codes can be used for V3 Max.

Please drop your email on "Notify Me When Available" if the product model is out of stock.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
Keychron V3 Max lsO layout 2.4G wireless QMK mechanical keyboard

Keychron V3 Max

ISO Layout Collection

The V3 Max is a QMK custom mechanical keyboard with 2.4 GHz wireless and Bluetooth 5.1 connection. It has a classic TKL layout and offers a gasket mount design, sound-absorbing foam, double-shot PBT keycaps, and more. The V3 Max is designed for a personalized experience and enhanced typing comfort.

Keychron-V3-Max-ISO-Layout-4.jpg__PID:a1a1ed4d-6411-4cb6-921a-f4f6ae844104
Keychron V3 Max lsO layout 2.4G wireless QMK mechanical keyboard
Customize YourV3 Max ISO

Choose the keycaps, switches, and more accessories for your V3 Max ISO

V3 Max ISO Layout Version

These versions include the UK, German, Swiss, Spanish, French, and Nordic layouts, all with extra keycaps suitable for Mac and Windows devices.

🇬🇧 UK-ISO Layout(PBT)

keychron-v3-max-qmk-wireless-custom-mechanical-keyboard-tkl-uk-iso-layout-fully-assembled-knob-for-mac-windows-linux__PID:67c74545-fc47-41bc-8057-52e23d097dd6

🇩🇪 DE-ISO Layout (PBT)

keychron-v3-max-qmk-wireless-custom-mechanical-keyboard-tkl-german-iso-layout-fully-assembled-knob-for-mac-windows__PID:4545fc47-11bc-4057-92e2-3d097dd65cba

🇨🇭Swiss-ISO Layout(PBT)

keychron-v3-max-qmk-wireless-custom-mechanical-keyboard-tkl-swiss-iso-layout-fully-assembled-knob-for-mac-windows-linux__PID:fc4711bc-c057-42e2-bd09-7dd65cba8c8d

🇩🇰 🇫🇮 🇮🇸 🇳🇴 🇸🇪 Nordic-ISO Layout (PBT)

keychron-v3-max-qmk-wireless-custom-mechanical-keyboard-tkl-nordic-iso-layout-fully-assembled-knob-for-mac-windows-linux__PID:11bcc057-52e2-4d09-bdd6-5cba8c8df690

🇫🇷 French-ISO Layout (ABS)

keychron-v3-max-iso-french-layout__PID:c05752e2-3d09-4dd6-9cba-8c8df6908f9c

🇪🇸 Spanish-ISO Layout (ABS)

keychron-v3-max-iso-spanish-layout__PID:52e23d09-7dd6-4cba-8c8d-f6908f9cf4ce
Customize Your Q3 Pro

Choose the keycaps, switches and more accessories for your Q3 Pro

All-Around Customizable Keyboard

To build a fully customizable keyboard, we designed every component to be easily assembled so you can customize and adjust any or every parts the way you want.

Structure-of-Keychron-V3-Max-2.4G-wireless-QMK-mechanical-keyboard-ISO-Layout-Mobile.jpg

2.4 GHz & Bluetooth Connection

Experience peak gaming performance on the fly with the 2.4 GHz wireless connection boasting a rapid 1000 Hz polling rate. For seamless multitasking across your computer, phone, and tablet, you can effortlessly connect the V3 Max via Bluetooth 5.1 to three devices.


Dual Receivers

For a better 2.4 GHz wireless experience, the V3 Max comes with Type-C and Type-A receivers. Enjoy the quick plug-and-play time. Or, put them away in the keyboard magnetic storage slot at the top right corner.

Wireless Receivers
Keychron-V3-Max-ISO-Layout.jpg__PID:f4f6ae84-4104-48b2-8d97-8b10c0ea6a47

An Epic Core Inside The Keyboard

A powerful ARM architecture MCU equipped with 256K Flash will provide more flexibility for developers. The polling rate is 1000 Hz right out of the box, which makes the latency hardly noticeable even in competitive games.

OSA Profile Double-shot PBT Keycaps

These double-shot PBT keycaps have a similar height to the OEM profile and has an SA-like shape. We named it the OSA (OEM spherical angled) keycap. The PBT keycaps will provide excellent oil resistance, enhance the type feel, and prevent the legends from fading out.


Switch Layouts Between macOS & Windows

Built with the Mac users’ experience in mind while still retaining compatibility for Windows devices, the Keychron V3 Max comes with a system toggle and an additional set of customized keycaps for both Windows and macOS systems. You can now save two different layouts on the keyboard, one for each system.

Gasket Mount Design

By adopting a gasket mount design along with a PC (Polycarbonate) plate, the V1 Max reduces acoustic resonance, delivering a softer and quieter typing experience with enhanced flexibility.

Double-Gasket Design
pfLauncher

Program with QMK & Launcher.

The open-source QMK firmware means endless possibilities for key remapping, macros, shortcuts, and more. Now you can easily customize each key with the Keychron Launcher web app.

Program the K14 Pro keyboard with Launcher
Click here to use Keychron Launcher

*Please use the latest version of Chrome / Opera / Edge browser to open the Launcher and connect the keyboard to your device via wired mode.

Hot-Swappable

The hot-swappable sockets are mounted on the PCB, so you can install or change the switches without soldering. The PCB supports both 3-pin and 5-pin MX mechanical switches.


South-facing RGB LED Lights

The south-facing RGB LED is designed to better illuminate the keyboard backlight from the typist’s angle with the premium non-shine-through PBT keycaps installed. The south-facing RGB is also free from interference when the users install OEM or Cherry-profile alternative keycaps on the keyboard.

Gateron Jupiter Switch

Our exclusive Gateron Jupiter mechanical switch (for the Fully Assembled version only) comes with a 3-pin design, its pre-lubed with a reliable Gateron quality standard with up to 80 million keystrokes lifespan. While their unique LED diffuser design offers high RGB backlight transmittance and softer backlight effect.
The banana switch provides an early tactile bump at the top with a uniquely smooth experience like those Panda switches on the market.

Gateron Jupiter Switch Features
PCB Stabilizers

Screw-In PCB Stabilizers

Even small part matters for your fingertip feel. We’ve integrated the PCB-mounted screw-in stabilizers for a smoother typing experience with less wobbliness on the big keys such as space bar, shift, enter, and delete. The Keychron V1 Max also supports third-party screw-in PCB stabilizers.

What's in the box?

Differences Between the V1 Max and V1

Specs

Width149 mm
Length367.8 mm
Front Height23.6 mm (without keycaps
Back Height32.5 mm (without keycaps)
Feet Height2 mm
Angle4° / 7° / 10°
Weight895 ± 10 g (Fully Assembled Version)
Body MaterialABS Plastic
Plate MaterialPC
Keycaps (Fully Assembled Version)Double-shot PBT keycaps, not shine-through, OSA Profile (OEM height, SA shape)
SwitchesGateron Jupiter (Fully Assembled Version)
Hot-swappable Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX, Kailh, etc.
StabilizerScrew-in PCB stabs
CableType-C cable + Type-A to Type-C adapter
MCUARM Cortex-M4 32-bit STM32F402 (256KB Flash)
Charging PortUSB Type-C
Operating Environment-10℃ to 50℃
Polling Rate1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode)
Mount Style Gasket Mount Design
BacklightSouth-facing RGB LED
N-Key Rollover (NKRO) Windows/macOS/Linux
Compatible System Type-C cable + Type-A to Type-C adapter
Bluetooth Version 5.1
Bluetooth Device NameKeychron V3 Max
Battery4000 mAh Rechargeable li-polymer battery
Charging Time  Around 5 hours
Wireless Working Time (Backlit off) Up to 225 hours (Lab test result may vary by actual use)
Wireless Working Time (RGB) Up to 100 hours (Lowest brightness)
Keychron V3 Max User Guide

Learn more about the Keychron V3 Max such as the V3 Max shortcuts, assembling the V3 Max, factory reset, and more in the FAQ section.
